GSW // HI-FINITY SLIDING DOORS REYNAERS BY GSW

An infinite view with ultimate performances

The Hi-Finity patio door is the epitome of modern design, combining the ultimate in contemporary aesthetics with outstanding performance. This state-of-the-art structurally glazed door offers the possibility of floor-to-ceiling and wall-to-wall glass, an ergonomically designed handle and a concealed locking system. For the discerning householder or architect who wants the very latest in contemporary design and ultimate performance, the Hi-Finity door sets a new benchmark of excellence.

DESIGNED NOT TO BE SEEN

Beautiful as it is, the Hi-Finity door is designed to be looked through, not to be looked at. The outer frame can be built into the structure of the building, making the dream of floor-to-ceiling and wall-to-wall glass a reality. The interlock between door panels is incredibly narrow, measuring only 1.37 inches wide, and the frame and spacer bars between the panes of glass are both black, helping the door to frame your view in a most unobtrusive way.

TECHNICAL INFORMATION

Max dimensions – (HxW) 158 x 138 inches
Thermal insulation – (Uf)1.4 W/m²K
Water tightness – E750 (750 Pa)
Wind load resistance – C5 (2000 Pa)
Acoustic performance – Rw(C;Ctr) = 46 (-1;-3) dB
Air tightness max. test pressure – 4 (600 Pa)
Energy level – Passive

Note: Performances may be different depending on the profile combinations.

By combining these huge door panels in a range of double track and triple track designs, Reynaers can offer a truly panoramic expanse of glass to make the most of any view. It is even possible to combine two Hi-Finity doors on adjoining walls using one of a range of innovative corner solutions.

The handle for the Hi-Finity sliding door is nothing less than a beautifully crafted masterpiece. Its slim design perfectly complements the contemporary styling of the door, and the soft touch materials and ergonomic design will bring a smile to your face every time you use it

BIG AND BEAUTIFUL

With a towering maximum door height of 11 feet and a maximum door panel weight of as much as 661 lbs, the Hi-Finity door stretches the boundaries of what is possible in terms of size.

The specially designed wheelbase ensures the fluid movement of the glass panes. Even panes for large openings can effortlessly be operated by hand. The operation of the sliding panes happens either manually, automatically or remoted controlled.

Enjoy an infinite view with ultimate performances! The ultra-slim design of the Hi-Finity sliding door creates large transparent surfaces, with a light, sleek and elegant appearance.

Security

The concept of the locking mechanism gives the door a high level of security. In combination with layered glass, Hi-Finity is burglary resistant, class RC2. The electric locking and unlocking is realized by a robust bolt and hook, operated by a simple push on the button or the remote control.

Full comfort

A dedicated and fully concealed motor ensures that the Hi-Finity sliding door opens and closes automatically, by the use of a switch or by connecting the motor to your home automation system. This high performance motor, with a capacity up to 1600 lbs, guarantees optimum convenience during use and is a safe and reliable solution.

Minimalistic design

By integrating the aluminum profiles into the walls, the glass surfaces are extending from floor to ceiling, creating the ultimate minimalistic appearance, merging indoor and outdoor into one. An extra design aspect is given by the design handle that has a slim, elegant and streamlined appearance.

High energy performance

The large glass surfaces of Hi-Finity give a great feeling of comfort, by offering the thermal efficient solutions of double and triple glazing. With Ud values of less than 1.0 W/m2K, these glass panels are perfectly suited for low energy houses. Consequently, Hi-Finity has been awarded the energy-saving Minergie quality label.
